The unival XWJ2-CASE is a portable multi modal smart jamming system designed for rapid deployment in conference rooms, secured indoor spaces, and temporary operational environments.

It is built on the XWJ2 modular jammer platform and utilizes FPGA controlled Direct Digital Synthesizer technology to generate programmable interference signals across a wide continuous frequency range from 20 MHz to 7200 MHz.

The system supports freely programmable sweep profiles, ultra fast step timing down to 16 nSec, and ICW channel walking functionality for effective interference of narrowband receivers.

The modular plug in architecture allows configuration with broadband or band specific amplifier units, with output power per module ranging from 30 to 150 watts depending on configuration.

Power supply can be provided via 110 to 220 VAC mains or 28 V DC, enabling both stationary and field deployment.

Control and configuration are possible via front panel keys, remote control unit, USB, or LAN. Multiple systems can be managed through a LAN network from a single PC.

The system includes digital temperature control, real time monitoring of temperature and power levels, and hardware locking of navigation frequencies where required.
